Casing/Horizontal Casing

Steel casing pipe for any project.

From start to finish, Pittsburgh Pipe helps your project stay in working order with the right type of casing for the job. Whether you’re in need of a steel casing pipe, horizontal casing, or a similar style casing, we handle every step of the process to bring you a perfectly manufactured product you can rely on.

Seamless Casing Pipe

Our staff works with your contractor, project manager, or facilities supervisor to understand what our products will be used for so we can make sure you choose a long-lasting option that satisfies your needs. This allows us to provide not only the steel pipe and casing required for the job, but also the drawings, manufacturing procedures, certifications and other documentation needed to get your pipe casing approved for the project. We partner with our customers from bid through project completion and make sure the casing pipe we deliver to their job sites meets requirements and all requested documentation is submitted for approval.

We stock casing pipe in sizes from 10 ¾ inches through 72-inch O.D., and custom manufacture pipe casing in 30-inch O.D. and up, in wall thicknesses from .312 inches through 1.250 inches, in uniform lengths or in custom lengths from 4 feet through 60 feet. We can also provide special end preparations, attachments such as weld bands and grout holes, and O.D. and I.D. coatings.

Casing Spacers

When you need to install water and sewer carrier pipes in casing, Pittsburgh Pipe offers a number of casing spacer solutions made from popular materials such as stainless steel, galvanized steel, epoxy coated steel, and polyethylene. Casing insulators are used to support and insulate the carrier pipes within the casing. They also eliminate the need to fill the annulus within the casing with sand to insulate the inner pipe. By eliminating the inner fill, the casing and inner pipe can easily be repaired or removed later if needed which lowers installation and maintenance costs. These spacers are corrosion resistant and require no special tools or grease for installation; they are simply bolted on and secured to the casing.

Customizable casing spacer solutions for your unique project

Spacers for multiple pipes within one casing are available as well. We can also make spacers with special risers so that the invert of the carrier pipe can be aligned to grade properly in the field. Each end of the casing pipe can be sealed off with our most popular wrap-around casing end seals or with our pull-on end seals. Link seals are also available. Our engineers can customize your casing spacer solution by incorporating:

· Multiple carriers in one casing

· Thermally insulated pipe without damage to insulation

· Smaller carriers in larger casings

· Wheeled spacers for large diameter pipe

The material you buy from Pittsburgh Pipe can be customized to suit your project’s unique needs. We have the ability to manufacture casing spacers in the quantity you need at a competitive price and have it delivered exactly when you need it. All of our casing spacers and end seals are manufactured in the USA. Your casing spacers and end seals will usually ship two to three business days after your order is placed. Here are products and features we can add to your customized solution:

· Stainless steel Casing spacers

· Galvanized casing spacers

· Epoxy coated casing spacers

· Polyethylene casing spacers

· Casing spacers with rollers

· Multiple pipe casing spacers

· Cut-to-fit casing spacers

· Bevel by bevel

· Wrap-around casing end seals

· Pull-on end seals

Any material we deliver will be accompanied with our signature post-delivery support. Our technicians can supply complete shop drawings, quality assurance/quality control documentation, and certificates of compliance so that you are prepared for any inspection. Pittsburgh Pipe also will have a casing spacer expert on call 24/7 to help answer any questions or address any issues.

End Seals

Traditionally, end seals were made of brick. But as plastic and rubber technology has evolved, the preferred material for end seals has been EPDM rubber that expands and contracts to ambient temperatures and will not crack and fail as brick is apt to do. Casings are used for underground placement of carrier pipe beneath highways, thoroughfares, railroads, and through commercial and residential areas. End seals have the all-important task of keeping the casing pipe dry and protecting it against corrosion.

End seals pull over carrier pipe and the casing pipe. The end seal boot is then secured by steel straps for easy installation. End seals will homogenize the system and prevent leaks and pipe failure. If the pipe has a bore grade change, the end seal is long enough to adjust to the pipe and conditions. Customizable end seal solutions for your unique project

Our end seals can be customized to meet your unique needs. Whether it is for an existing pipe system or if you are looking to install new casing or new construction, Pittsburgh Pipe has the correct materials to satisfy any unique requirement.

Quality Materials And Dependable Service From Pittsburgh Pipe
The material you buy from Pittsburgh Pipe can be customized to suit your project’s unique needs. We have the ability to manufacture casing spacers and end seals in the quantity you need at a competitive price and have it delivered exactly when you need it. All of our end seals are manufactured in the USA. Your casing spacers and end seals will usually ship two to three business days after your order is placed. Here are products and features we can add to your customized solution:

· Bevel by bevel

· Wrap-around casing end seals

· Pull-on end seals

Any material we deliver will be accompanied with our signature post-delivery support. Our technicians can supply complete shop drawings, quality assurance/quality control documentation, and certificates of compliance so that you are prepared for any inspection.

Pittsburgh Pipe also will have an end seal expert on call 24/7 to help answer any questions or address any issues.

A manufacturing company like ours doesn’t stay in business for as long as we have by ignoring the needs of our customers or delivering inferior products. Our service goes beyond the sale, and we stand by our products and our quality long after the materials have been delivered. Call Pittsburgh Pipe today for a free consultation and review. We are confident that the quality of our products, the ease and speed of our service, and the value we provide will make sure your project or repair is done properly the first time.
