Weld Bands/Reinforcing Bands

Pipe-strengthening welds and reinforcing bands.

A weld band is provided either loose or attached and is used to create a female end on steel pipe in order to ease field fit up.

Weld Bands

The material you buy from Pittsburgh Pipe can be customized to suit your project’s unique needs. We can manufacture weld bands in the quantity you need at a competitive price and have it delivered exactly when you need it. Your welding bands can be made to any custom specification your job requires and can be sent attached to your pipe or sent separately. Weld bands are furnished loose or they are provided by fillet welding the band ½ on and ½ off one end of the pipe forming a female end in order to ease field fit up and welding to the male end of an adjacent pipe. Weld bands are also sometime referred to as alignment bands or wedding bands.

Here are products and features we can add to your customized solution:

  • Weld bands sized from 6” to 120”
  • Band thicknesses from .375” to 1.50
  • Weld bands can be supplied in any length
  • Weld bands can be either loose or attached (to the O.D. or the I.D.)

When you have a ramming, auger boring or pipe jacking job and strength is what you need, Pittsburgh Pipe also manufactures overcut bands to reinforce the ends of your pipes. An overcut band for horizontal casing is typically ID formed slightly larger than the pipe OD.  It is furnished loose or is provided by fillet welding the band flush to the pipe end or about ½” off one end of the pipe. An overcut band is attached to the lead piece of the bore casing so that as the bore string advances through the ground its larger diameter overcuts the borehole thereby reducing skin friction on the following casings.

Overcut bands are sometimes furnished with a notch or keyway which may help to prevent casing twist and to keep the bore on line.

Our overcut bands have the following features:

  • Typically 6”-12” long
  • Band thicknesses from .375” to .500”
  • O.D. installed flush or near flush with the end of the pipe
  • Our overcut bands can be custom manufactured to your exact project specifications

Any material we deliver is accompanied by our signature post-delivery support. Our technicians can supply complete shop drawings, quality assurance/quality control documentation, and certificates of compliance, so you’re prepared for any inspection. Pittsburgh Pipe also has a steel welding band expert on call 24/7 to help answer any questions or address any issues.

Pipe Casing Services

You need a high-quality casing to match your weld and Pittsburgh Pipe has the services to help.

Weld Bands For Any Project

A manufacturing company like ours doesn’t stay in business for as long as we have by ignoring the needs of our customers or delivering inferior products. Our service goes beyond the sale, and we stand by our products and quality long after the materials have been delivered.

With Pittsburgh Pipe, you can rest assured you’re purchasing the best possible materials for your project. Whether you are repairing existing structures or building new, we can customize any material in any quantity. This ensures your limited budget is being used wisely to purchase the best products available. Call Pittsburgh Pipe today for a free consultation, and we can show you how we can bring your company the best results on your investment.

Our welding bands are available in a wide array of sizes and thicknesses and can be customized in any quantity to satisfy your project’s individual needs.

Custom Shaft Bands

Shaft bands, vertical casing, and more can be found through the professional services of Pittsburgh Pipe.
